ORM UoDs

Examples from the Real World

Databases (or potential ones) are all around us. ORM requires us to look critically at sections of the real world and extract the underlying FACT TYPES that could be used to describe that information. We do this by first writing ELEMENTARY SENTENCES.

An elementary sentence is a FACT TYPE with embedded data - for example:

Person(pid)42 scored Rating(achievement code)"HA"
in Subject(subject code)"Ec"

where:

Entity/Object Types
Person, Rating and Subject
Reference Modes
pid, achievement code and subject code
role
... scored ... in ...
Example data
42, "HA" and "EC"

An Elementary sentence is one that cannot be broken down further into simpler ones without the loss of important information.

In the above sentence, if we decomposed it into 2 simpler (binary) sentences:

Person(pid) scored Rating(achievement code)
Person(pid) studies Subject(subject code)

We lose the relationship between a student and the achievement in that particular subject.


Examine the following real-world examples and try to write ELEMENTARY SENTENCES for them.

Survey Results Ekka Showbag
Woolies Docket Concert Ticket

Restauant Bill
